Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit

Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit
Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit
Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit

Large Image :  Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Fuchuan
Certification: CE
Model Number: FC-650B
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 23000-29000 / Set
Packaging Details: Export grade wooden case with shock-proof packing
Delivery Time: 15-45 working days after deposit
Payment Terms: T/T,L/C,Western Union
Supply Ability: 20 Sets per Month
Contact Now

Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit

Description
Model: FC-650B Single Wire Diameter: 0.16-1.04 Mm
Stranding Section Area: 0.4-6.0 Mm2 Pitch Range: 11.6-100 Mm
Max Rotating Speed: 2000 Rpm (4000 Twist/min) Main Motor Power: 7.5 KW
Tension Control: Touch Screen + PLC + Magnetic Powder Clutch Brake Mode: Electromagnetic Brake
Drive: Inverter Driven Main Motor Operation Mode: Touch Screen
Take-up Bobbin: 630 Mm Outer Diameter Dimension: 3200L X 1800W X 1700H Mm
Highlight:

FC-650B copper wire bunching machine

,

high speed double twist stranding unit

,

electrical wire bunching machine

Electrical Wire Bunching Machine High Speed Double Twist Design FC-650B Copper Stranding Unit

High-speed double twist design for double output per spindle rotation

Electrical wire bunching machine FC-650B with high-speed double twist design, inverter driven, 7.5KW, CE certified.

Key Features

  • High-speed double twist design for electrical wire stranding
  • Inverter driven for smooth speed and energy saving
  • Precise tension and pitch via touch screen PLC
  • Automatic stop at preset length
  • Compact and quiet for workshop installation

Technical Specifications

Model FC-650B
Single Wire Diameter 0.16-1.04 mm
Stranding Section Area 0.4-6.0 mm2
Pitch Range 11.6-100 mm
Max Rotating Speed 2000 rpm (4000 twist/min)
Main Motor Power 7.5 KW
Tension Control Touch screen + PLC + magnetic powder clutch
Brake Mode Electromagnetic brake
Drive Inverter driven main motor
Operation Mode Touch screen
Take-up Bobbin 630 mm outer diameter
Dimension 3200L x 1800W x 1700H mm

Capacity & Application

Suited to 0.4-6.0 mm2 electrical conductor bunching for power cord, appliance wire and cable production.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-650B high-speed double twist wire bunching machine.
