Silver Jacketed Wire Bunching Machine High Speed Double Twist Design FC-500B Stranding Equipment

Large Image : Silver Jacketed Wire Bunching Machine High Speed Double Twist Design FC-500B Stranding Equipment

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-500B-2S

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 17000-22000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Silver Jacketed Wire Bunching Machine High Speed Double Twist Design FC-500B Stranding Equipment

Description

Model:	FC-500B-2S	Single Wire Diameter:	0.10-0.50 Mm
Stranding Section Area:	0.5-4.0 Mm2	Pitch Range:	15-120 Mm (12 Zones)
Max Rotating Speed:	3000 Rpm (6000 Twist/min)	Main Motor Power:	5.5 KW
Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch	Brake Mode:	Electromagnetic Brake
Direction Of Lay:	Optional Right Or Left	Operation Mode:	Touch Screen
Take-up Bobbin:	500 Mm Outer Diameter	Dimension:	2900L X 1600W X 1500H Mm
Highlight:	FC-500B wire bunching machine , high speed double twist stranding , silver jacketed wire bunching equipment

Silver Jacketed Wire Bunching Machine High Speed Double Twist Design FC-500B Stranding Equipment

High-speed double twist design for double output per spindle rotation

Silver jacketed wire bunching machine FC-500B with high-speed double twist design, adjustable lay direction, 5.5KW, CE certified.

Key Features

High-speed double twist design for fine silver jacketed wire
Optional right or left lay direction
Adjustable pitch and winding breadth
Gentle tension protects delicate plated surfaces
Compact, quiet and energy efficient

Technical Specifications

Model	FC-500B-2S
Single Wire Diameter	0.10-0.50 mm
Stranding Section Area	0.5-4.0 mm2
Pitch Range	15-120 mm (12 zones)
Max Rotating Speed	3000 rpm (6000 twist/min)
Main Motor Power	5.5 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Direction of Lay	Optional right or left
Operation Mode	Touch screen
Take-up Bobbin	500 mm outer diameter
Dimension	2900L x 1600W x 1500H mm

Capacity & Application

Ideal for 0.5-4.0 mm2 silver jacketed and fine plated conductor bunching in precision cable and electronic wire lines.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-500B-2S high-speed double twist wire bunching machine.
