Automatic Wire Bunching Machine High Speed Double Twist Design FC-630B Copper Stranding Unit

Large Image : Automatic Wire Bunching Machine High Speed Double Twist Design FC-630B Copper Stranding Unit

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-630B-2

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 22000-28000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Automatic Wire Bunching Machine High Speed Double Twist Design FC-630B Copper Stranding Unit

Description

Model:	FC-630B-2	Single Wire Diameter:	0.15-0.80 Mm
Stranding Section Area:	1.0-8.0 Mm2	Pitch Range:	20-150 Mm (12 Zones)
Max Rotating Speed:	2200 Rpm (4400 Twist/min)	Main Motor Power:	7.5 KW
Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch	Brake Mode:	Electromagnetic Brake
Traverse Method:	Rolling Ring Drive, Adjustable Pitch	Operation Mode:	Touch Screen
Take-up Bobbin:	630 Mm Outer Diameter	Dimension:	3200L X 1800W X 1700H Mm
Highlight:	Automatic Wire Bunching Machine , High Speed Double Twist Buncher , FC-630B Copper Stranding Unit

Automatic Wire Bunching Machine High Speed Double Twist Design FC-630B Copper Stranding Unit

High-speed double twist design for double output per spindle rotation

Automatic wire bunching machine FC-630B with high-speed double twist design, 7.5KW, touch screen PLC operation, CE certified.

Key Features

Automatic high-speed double twist bunching with touch screen control
Precise PLC tension and pitch adjustment
Auto stop at preset length and wire break
Energy saving and quiet running
Ideal for fine copper and alloy wire stranding

Technical Specifications

Model	FC-630B-2
Single Wire Diameter	0.15-0.80 mm
Stranding Section Area	1.0-8.0 mm2
Pitch Range	20-150 mm (12 zones)
Max Rotating Speed	2200 rpm (4400 twist/min)
Main Motor Power	7.5 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Traverse Method	Rolling ring drive, adjustable pitch
Operation Mode	Touch screen
Take-up Bobbin	630 mm outer diameter
Dimension	3200L x 1800W x 1700H mm

Capacity & Application

Suited to 1.0-8.0 mm2 fine conductor bunching for enamel wire, data cable and electronic wire production.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-630B-2 high-speed double twist wire bunching machine.
