Tinned Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Twister

Large Image : Tinned Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Twister

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-1000B-2T

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 46000-56000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Tinned Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Twister

Description

Model:	FC-1000B-2T	Single Wire Diameter:	0.30-1.70 Mm
Stranding Section Area:	6.0-35.0 Mm2	Pitch Range:	35-200 Mm (12 Zones)
Max Rotating Speed:	1000 Rpm (2000 Twist/min)	Main Motor Power:	18.5 KW
Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch	Brake Mode:	Electromagnetic Brake
Traverse Method:	Rolling Ring Drive, Adjustable Pitch	Operation Mode:	Touch Screen
Take-up Bobbin:	1000 Mm Outer Diameter	Dimension:	4000L X 2200W X 2100H Mm
Highlight:	FC-1000B copper wire bunching machine , high speed double twist twister , tinned wire bunching machine

Tinned Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Twister

High-speed double twist design for double output per spindle rotation

Tinned wire bunching machine FC-1000B with high-speed double twist design, 18.5KW, electromagnetic brake, CE certified.

Key Features

High-speed double twist design for tinned copper stranding
Constant tension ensures uniform lay and surface finish
Automatic brake on wire break and stop at preset length
Robust build for continuous heavy-duty operation
Compatible with bare, tinned and silver jacketed wire

Technical Specifications

Model	FC-1000B-2T
Single Wire Diameter	0.30-1.70 mm
Stranding Section Area	6.0-35.0 mm2
Pitch Range	35-200 mm (12 zones)
Max Rotating Speed	1000 rpm (2000 twist/min)
Main Motor Power	18.5 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Traverse Method	Rolling ring drive, adjustable pitch
Operation Mode	Touch screen
Take-up Bobbin	1000 mm outer diameter
Dimension	4000L x 2200W x 2100H mm

Capacity & Application

Built for 6.0-35.0 mm2 tinned and bare copper conductor bunching in power cable and building wire production.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-1000B-2T high-speed double twist wire bunching machine.
