Bare Copper Wire Bunching Machine High Speed Double Twist Design FC-1000B 18.5KW Stranding

Large Image : Bare Copper Wire Bunching Machine High Speed Double Twist Design FC-1000B 18.5KW Stranding

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-1000B-2B

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 47000-57000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Bare Copper Wire Bunching Machine High Speed Double Twist Design FC-1000B 18.5KW Stranding

Description

Model:	FC-1000B-2B	Single Wire Diameter:	0.30-1.70 Mm
Stranding Section Area:	6.0-35.0 Mm2	Pitch Range:	35-200 Mm (12 Zones)
Max Rotating Speed:	1000 Rpm (2000 Twist/min)	Main Motor Power:	18.5 KW
Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch	Brake Mode:	Electromagnetic Brake
Traverse Method:	Rolling Ring Drive, Adjustable Pitch	Operation Mode:	Touch Screen
Take-up Bobbin:	1000 Mm Outer Diameter	Dimension:	4000L X 2200W X 2100H Mm
Highlight:	Bare copper wire bunching machine , High speed double twist stranding , 18.5KW wire bunching machine

Bare Copper Wire Bunching Machine High Speed Double Twist Design FC-1000B 18.5KW Stranding

High-speed double twist design for double output per spindle rotation

Bare copper wire bunching machine FC-1000B with high-speed double twist design, 18.5KW, PLC magnetic powder tension, CE certified.

Key Features

High-speed double twist design for large bare copper stranding
18.5KW main motor for high continuous output
PLC and magnetic powder clutch for stable tension
Automatic brake on break and preset length stop
Heavy-duty structure for 24-hour operation

Technical Specifications

Model	FC-1000B-2B
Single Wire Diameter	0.30-1.70 mm
Stranding Section Area	6.0-35.0 mm2
Pitch Range	35-200 mm (12 zones)
Max Rotating Speed	1000 rpm (2000 twist/min)
Main Motor Power	18.5 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Traverse Method	Rolling ring drive, adjustable pitch
Operation Mode	Touch screen
Take-up Bobbin	1000 mm outer diameter
Dimension	4000L x 2200W x 2100H mm

Capacity & Application

Rated for 6.0-35.0 mm2 bare copper conductor bunching, appropriate for power cable and bare wire manufacturing.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-1000B-2B high-speed double twist wire bunching machine.
