Core Wire Bunching Machine High Speed Double Twist Design FC-800B Copper Stranding Equipment

Large Image : Core Wire Bunching Machine High Speed Double Twist Design FC-800B Copper Stranding Equipment

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-800B-2C

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 34000-42000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Core Wire Bunching Machine High Speed Double Twist Design FC-800B Copper Stranding Equipment

Description

Model:	FC-800B-2C	Single Wire Diameter:	0.20-1.20 Mm
Stranding Section Area:	2.5-16.0 Mm2	Core Wire Diameter:	2.0-5.0 Mm
Pitch Range:	30-180 Mm (12 Zones)	Max Rotating Speed:	1500 Rpm (3000 Twist/min)
Main Motor Power:	11 KW	Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch
Brake Mode:	Electromagnetic Brake	Operation Mode:	Touch Screen
Take-up Bobbin:	800 Mm Outer Diameter	Dimension:	3600L X 2000W X 1900H Mm
Highlight:	FC-800B copper wire bunching machine , high speed double twist bunching machine , copper stranding equipment

Core Wire Bunching Machine High Speed Double Twist Design FC-800B Copper Stranding Equipment

High-speed double twist design for double output per spindle rotation

Core wire bunching machine FC-800B with high-speed double twist design, preset length auto stop, 11KW, CE certified.

Key Features

High-speed double twist design for core wire bunching
Handles core wire plus multi-strand outer conductors
Preset length auto stop for accurate bobbins
Constant tension control for uniform lay
Reliable electromagnetic braking on faults

Technical Specifications

Model	FC-800B-2C
Single Wire Diameter	0.20-1.20 mm
Stranding Section Area	2.5-16.0 mm2
Core Wire Diameter	2.0-5.0 mm
Pitch Range	30-180 mm (12 zones)
Max Rotating Speed	1500 rpm (3000 twist/min)
Main Motor Power	11 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Operation Mode	Touch screen
Take-up Bobbin	800 mm outer diameter
Dimension	3600L x 2000W x 1900H mm

Capacity & Application

Used for 2.5-16.0 mm2 core and conductor bunching in cable assembly and wire harness production.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-800B-2C high-speed double twist wire bunching machine.
