Copper Wire Bunching Machine High Speed Double Twist Design FC-800B Stranding Equipment

Large Image : Copper Wire Bunching Machine High Speed Double Twist Design FC-800B Stranding Equipment

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-800B-2

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 32000-40000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Copper Wire Bunching Machine High Speed Double Twist Design FC-800B Stranding Equipment

Description

Model:	FC-800B-2	Single Wire Diameter:	0.20-1.20 Mm
Stranding Section Area:	2.5-16.0 Mm2	Pitch Range:	30-180 Mm (12 Zones)
Max Rotating Speed:	1500 Rpm (3000 Twist/min)	Main Motor Power:	11 KW
Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch	Brake Mode:	Electromagnetic Brake
Traverse Method:	Rolling Ring Drive, Adjustable Pitch	Operation Mode:	Touch Screen
Take-up Bobbin:	800 Mm Outer Diameter	Dimension:	3600L X 2000W X 1900H Mm
Highlight:	Copper wire bunching machine , High speed double twist stranding , FC-800B wire bunching equipment

Copper Wire Bunching Machine High Speed Double Twist Design FC-800B Stranding Equipment

High-speed double twist design for double output per spindle rotation

Copper wire bunching machine FC-800B with high-speed double twist design, 11KW motor, constant tension control, CE certified.

Key Features

High-speed double twist design for higher stranding efficiency
Uniform tension from empty to full bobbin
Automatic wire break protection and length stop
Compact footprint with low energy consumption
Stable performance for copper and alloy conductors

Technical Specifications

Model	FC-800B-2
Single Wire Diameter	0.20-1.20 mm
Stranding Section Area	2.5-16.0 mm2
Pitch Range	30-180 mm (12 zones)
Max Rotating Speed	1500 rpm (3000 twist/min)
Main Motor Power	11 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Traverse Method	Rolling ring drive, adjustable pitch
Operation Mode	Touch screen
Take-up Bobbin	800 mm outer diameter
Dimension	3600L x 2000W x 1900H mm

Capacity & Application

Designed for 2.5-16.0 mm2 copper conductor bunching, well suited to medium-capacity cable and enamel wire production.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-800B-2 high-speed double twist wire bunching machine.
