Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Stranding Equipment 18.5KW

Large Image : Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Stranding Equipment 18.5KW

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Fuchuan
Certification:	CE
Model Number:	FC-1000B-2

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 45000-55000 / Set
Packaging Details:	Export grade wooden case with shock-proof packing
Delivery Time:	15-45 working days after deposit
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	20 Sets per Month

Contact Now

Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Stranding Equipment 18.5KW

Description

Model:	FC-1000B-2	Single Wire Diameter:	0.30-1.70 Mm
Stranding Section Area:	6.0-35.0 Mm2	Core Wire Diameter:	2.0-5.0 Mm
Pitch Range:	35-200 Mm (12 Zones)	Max Rotating Speed:	1000 Rpm (2000 Twist/min)
Main Motor Power:	18.5 KW	Tension Control:	Touch Screen + PLC + Magnetic Powder Clutch
Brake Mode:	Electromagnetic Brake	Traverse Method:	Rolling Ring Drive, Adjustable Pitch
Operation Mode:	Touch Screen	Dimension:	4000L X 2200W X 2100H Mm
Highlight:	FC-1000B copper wire bunching machine , high speed double twist stranding equipment , 18.5KW wire bunching machine

Wire Bunching Machine High Speed Double Twist Design FC-1000B Copper Stranding Equipment 18.5KW

High-speed double twist design for double output per spindle rotation

High-speed double twist wire bunching machine FC-1000B for copper and alloy wire stranding, 18.5KW, touch screen control, CE certified.

Key Features

High-speed double twist design doubles output per spindle rotation
Constant tension from empty to full bobbin via magnetic powder clutch
Automatic brake on wire break and stop at preset length
Low noise, low power, compact floor space
Applies to bare copper, tinned, silver jacketed and enamelled wire

Technical Specifications

Model	FC-1000B-2
Single Wire Diameter	0.30-1.70 mm
Stranding Section Area	6.0-35.0 mm2
Core Wire Diameter	2.0-5.0 mm
Pitch Range	35-200 mm (12 zones)
Max Rotating Speed	1000 rpm (2000 twist/min)
Main Motor Power	18.5 KW
Tension Control	Touch screen + PLC + magnetic powder clutch
Brake Mode	Electromagnetic brake
Traverse Method	Rolling ring drive, adjustable pitch
Operation Mode	Touch screen
Dimension	4000L x 2200W x 2100H mm

Capacity & Application

Suitable for above seven strands of bare copper wire, tinned wire, silver jacketed wire and enamelled wire, producing 6.0-35.0 mm2 stranded conductors for cable and wire manufacturing lines.

Welcome to contact us for detailed quotation, sample testing and customization of the FC-1000B-2 high-speed double twist wire bunching machine.
