High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length

High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length
High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length

Large Image :  High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length

Product Details:
Place of Origin: CHINA
Brand Name: FUCHUAN
Certification: ISO9001 2008
Model Number: FC-T4
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: USD41000
Packaging Details: simply water proof packing
Delivery Time: 8weeks
Payment Terms: T/T

High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length

Description
Pay Off Method: Brush Pay Off Number Of Inlet Wire: 2pcs
Machine Color: Sky Blue Or Apple Green Fit For Wire: 1.04-2.52mm
Pay Off Bobbin: Diameter 300mm Annealing Method: Tube Annealing
Max Speed: 100m/min
High Light:

copper wire annealing machine

,

cable coiling machine

High Speed Big Wire Tinning Machine 3.0M Annealing Furnace Length





Quick detail:



Ultra-fine wire high speed tinning machine

The technology of this machine is brought from Japan and put in production in Jiangsu.



Characteristics:



Easy to operate, good annealing heat insulation, save power, adopt nitrogen or steam protection, have individual meter counter for each take up bobbin, stop automatically achieve the preset meter. It may realize ultra-fine annealing tin and achieve industry-leading level.



Specification:



Equipment models

FC-T4

Twisting usage

It is mainly applied to the annealing of ultra-fine round copper wire and alloy wire.

Single wire dia(mm)

φ0.68-φ2.52 mm

Max numbers of inlet wire

4pcs

Linear speed

Max:150m/min

Pay off method

Brush pay off

Pay off bobbin model

φ500bobbin

Annealing furnace length

3.0m

Annealing method

Tube annealing

Annealing protection method

Nitrogen protection or vapour protection

Tinned method

Hot dip

Capstan control method

Inverter+ motor control or adopt stepless speed regulation motor

Equipment total power

3.7kw

Take up control

Take up is voltage regulator control the moment motor

Take up bobbin size

400/500 bobbin

Traverse control method

Inverter+reducer motor control ball screw traversing,photoelectric induction reversing

Installation size

20000L*1250W*1850H

















































Other Information



FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
