Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire

Certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
Customer Reviews
The machine from Fuchuan is with high quality.We have confidence of its machine. And we have cooperation for many years. No 1 machine in China.

—— Mr Robert Klimko

I'm Online Chat Now

Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire

Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire
Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire
Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire

Large Image :  Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire

Product Details:
Place of Origin: CHINA
Brand Name: FUCHUAN
Certification: ISO9001 2008
Model Number: FC-T24
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: can quote to customer
Packaging Details: pallet packing
Delivery Time: 45days
Payment Terms: T/T, L/C
Supply Ability: 20sets/month

Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire

Description
Name: Wire Annealing Machine Machine Color: Sky Blue Or Apple Green
Fit For Wire: 0.15-0.64mm Inlet Wire Dia: 0.08~0.32mm Or 0.15~0.64mm
Max Nos Of Inlet Wire: 24 Linear Speed: Max:350m/min
Pay Off Method: Brush Pay Off Application: Ultra Fine Round Copper Wire
High Light:

wire tinning machine

,

copper wire annealing machine

,

Hot Dip Wire Annealing Machine



Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire 0

Hot Dip Tinned Wire Annealing Machine For Ultra Fine Round Copper Wire



Wire Annealing Machine Description:



  1. The annealer, oven and tinning furnace is tube type. Easy to replace and maintenance.
  2. The two ends of the furnace tube all ceramic sleeve design, to prevent the wire be scratched.
  3. The water tank is re-cycle design and with water tank and pump.
  4. The two ends of the hauling drum with revolving joints and can connect the re-cycle water for cooling.
  5. The take up is 44 heads single layer design. Another four heads is for prepare.
  6. Is fit for human’s height. Can be operated easily.



Wire Annealing Machine Specification:



Equipment model FC-T16 FC-T24 FC-T48 FC-T60
machine usage applied to the annealing and tinning of ultra-fine round copper wire and alloy wire.
inlet wire dia 0.08~0.32mm or 0.15~0.64mm 0.08~0.32mm 0.08~0.25mm
max nos of inlet wire 16 24 48 60
linear speed max:350m/min
pay off type brush pay off
pay off bobbin type dia300mm bobbin
annealing furnace length five meters or six meters
annealing type tube type annealing
annealing protection type water seal protection+notrogen or vapor protection
tinned type hot dip No
capstan control type inverter+motor control
equipment total power 53KW 61KW 98KW 87KW
take up control voltage adjusting controls torque motor take up
take up bobbin size five inch,eight inch or five inch,eight inch,10inch
traverse control type gear motor+inverter control toothrow traverse
installation size(mm) 14500L*1500W*2100H 18000L*1500W*2100H 28000L*1800W*2400H 26000L*1800W*2300H





Other information:



Terms of payment:

FOB Shanghai



Payment terms:



30% down payment,70% before shipment



Delivery time:



45days after receive the downpayment



Minimum order:



1set



Package:



With container
