FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm
FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

Large Image :  FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

Product Details:
Place of Origin: China JiangSu
Brand Name: Fuchuan
Certification: ISO9001:2008
Model Number: FC-35-1
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: discussable
Packaging Details: normal packing
Delivery Time: 45-60days
Payment Terms: T/T, L/C
Supply Ability: 500 SETS/YEAR

FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

Description
Material: FEP, FPA ,ETFE Plastic Screw Dia: 35
Feed Wire Type: Active Pay Off / Passive Pay Off Conductor Dia: 0.2-1.02mm
Finished Wire Dia: 0.6-1.67 Temp Control: Seven Zones
Screw L/D Ratio: 25:1
Highlight:

wire making machine

,

copper wire machine

FEP FPA ETFE Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm





Quick detail :



It is applicable to FEP(fep,say againF46),FPA(Oxidation of PVC resin silance oxygen radicals)and ETFE(say againF40)etc.fluorine plastic's production.



Specification:



Equipment type 35-1 45 65
revolving speed of screw(mm) φ35 φ45 φ65
Screw L/D ratio 25:1 25:1 25:1
Extrusion output(kg/h) 15 20 45
Power for main machine(kw) 11 11 22
conductor dia(mm) Φ0.2~1.02 Φ0.6~2.6 Φ1.0~5.0
finished wire dia(mm) Φ0.6~1.67 Φ1.0~3.2 core wireΦ1.5~6.0 sheathed wireΦ6.0~16
pay off type active pay off or passive pay off
pre-heater 5KVA 5KVA 5KVA
Evacuating device Vaccum generator
temp control seven zones seven zones eight zones
diameter measure device manual/laser automatic diameter tester device
cooling water tank single layer or double layer U type
capstan dia(mm) φ340 φ410 Φ510
capstan power 2.2KWspeed reduction motor
wire accumulator rack horizontal type
max of accumulator length 200M
Take-up Biaxial rooling
take up power 2.2KW 2.2KW 3.7KW
Total power 38KW 38KW 65KW



Other information:



active pay off or passive pay off



Terms of payment:



FOB Shanghai / Ningbo



Payment terms:



30% down payment,70% before shipment



Delivery time:



45-60 days after receive the downpayment



Origin:



China



Minimum order:



1set



Package:



With container
