Aerospace Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment

Aerospace  Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment
Aerospace  Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment Aerospace  Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment Aerospace  Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment Aerospace  Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment Aerospace  Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment

Large Image :  Aerospace Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment

Product Details:
Place of Origin: China JiangSu
Brand Name: Fuchuan
Certification: CE
Model Number: FC-400B-4
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: normal packing
Delivery Time: 45days
Payment Terms: T/T, L/C
Supply Ability: 20SET/PER MONTH

Aerospace Dia400mm High Rotation Speed Copper Wire Bunching Machine / Equipment

Description
Color: Sky Blue Fit For Bobbin: Diameter 400mm
For Wire: Bare Copper Wire/silver Jacketed Wire/enamelled Wire Wire Dia: 0.05-0.32mm
Wire: Core Wire Double Twist Magnetic Powder Clutch: 0.6kgf
Control Type: Computer Control
High Light:

automatic wire twister

,

wire twist machine

,

Aerospace Copper Wire Bunching Machine

FUCHUAN  Aerospace Copper High Rotation Speed Wire Bunching Machine/ Equipment  with Diameter 400mm 0.6kgf





Quick Details:



Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).



Characteristics:



1. High production speed, constant tension from empty to full bobbin, especially for high quality stranding wire.

2. Use shaft to calculate meters, less than 0.01% error for a certain wire&cable.

3. With FC-100 active back-twist pay-off machine to achieve bunching instead of twisting.

4. Especially for twisting small cross-section area.

5. Use synchronous belt drive,

6. Change guide wheel to change lay distance, easy to operate.



Specifications:



Equipment models FC-400B-4
Twisting usage It is applied to the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.
Single wire dia(mm) φ0.05-φ0.32
Stranding section area (mm²) 0.0137-1.0
Core wire single wire dia φ0.5-φ1.5
Core wire stranding outer dia φ1.0-φ3.5
Pitch(mm) 3.1-33.3(24zones)
Direction of lay Optional for right or left
Outer dia*bore*outer width φ400*φ56*300
Max rotating speed 3500(7000twist)
Main motor power 3.7KW
Inverter power 3.7KW
Tension control method Touch screen +PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbin
Magnetic powder clutch 0.6kgf
Protection Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.
Brake mode Electromagnetic brake
Traversing method Rolling ring drive units, winding pitch and breadth are adjustable



Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
