Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm

Certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
Customer Reviews
The machine from Fuchuan is with high quality.We have confidence of its machine. And we have cooperation for many years. No 1 machine in China.

—— Mr Robert Klimko

I'm Online Chat Now

Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm

Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm
Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm

Large Image :  Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm

Product Details:
Place of Origin: China JiangSu
Brand Name: Fuchuan
Certification: ISO9001:2008
Model Number: FC-50
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: normal water proof packing
Delivery Time: 45days
Payment Terms: T/T, L/C
Supply Ability: 500SET/PER YEAR

Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm

Description
Plastic: PVC Max Speed: 400m/min
Feed Wire Type: Active Pay Off Or Tension Pay Off Screw Dia: 50
Wire Diameter: Φ0.6-4 Color: Sky Blue
Extrusion Output: 85kg/h
High Light:

Dia 4mm Cable Extrusion Machine

,

Dia 0.6mm Cable Extrusion Machine

,

Sky Blue Cable Extrusion Machine

Fuchuan Cable Extrusion Machine For PVC Plastic Extrusion Wire Dia 0.6-4mm





Quick detail:



A Low smoking, non-halogen extruder line

B Photovoltaic extruder line



Specification:



Model FC-50
Screw Diameter Φ50
Screw L/D Ratio 26:1
Feed wire type Active pay off or tension pay off
Max speed(m/min) 400
Extrusion output 85
Power for main machine(KW) 15
Wire diameter Φ0.6-4
Accumulator Horizonal wire accumulator
Cooling channel Folding W type or U type
Capstan diameter Φ410
Capstan power 5HP
Take up power 3.7KW
Take up type 500-800 Double shaft take-up





Other information:



active pay off or passive pay off



Terms of payment:



FOB Shanghai / Ningbo



Payment terms:



30% down payment,70% before shipment



Delivery time:



45days after receive the downpayment



Origin:



China



Minimum order:



1set



Package:



With container
