Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine

Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine
Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine

Large Image :  Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine

Product Details:
Place of Origin: China Kunshan
Brand Name: FUCHUAN
Certification: CE
Model Number: FC-1+6+12
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: simple packing
Delivery Time: 8weeks
Payment Terms: T/T

Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine

Description
Fit For Wire: 19pcs Copper Wires φ0.16mm - φ0.64mm In One Time Fit For Bobbin: Diameter 630 Or 250mm
Wire: 19pcs Of Copper Wire Pay Off Bobbin: Dia180 Or Dia630
Take Up Bobbin: Dia630 Can Replace: Tube Bunching Machine
Stranding Section Area: 0.38-6.0mm2 Operation Mode: Touchscreen
High Light:

cable twisting machine

,

wire twist machine

,

Automatic Copper Wire Bunching Machine

4000Twist Copper Wire Bunching Machine With Touch Screen Operation





Description



It is the latest developed machine. This machine replace the model 200 tube bunching machine with the high productivity(It is 4.5times than tube machine for the 1+6+12 conductors normal bunching)low power, small floor place, low noise and other merits.



Features:





Equipment models

1+6+12(200bobbin)

FC-1+6+12(630bobbin)

Twisting usage

It is applicable to bunching 19pcs copper wires in one time

Single wire dia(mm)

φ0.16-φ0.64

Stranding section area (mm²)

0.38-6.0

Pitch(mm)

11.6-100(34zones)

Direction of lay

Optional for right or left

Pay off bobbin size

8inch,9inch

φ630*φ125*475

Max rotating speed

2000(4000twist)

2000(4000twist)

Pay off type

Mechanical friction

Magnetic tension

Pay off machine power

5.5KW

7.5KW

Take up bobbin size

φ630*φ125*475

φ630*φ125*475

Pay off Inverter power

7.5KW

7.5KW

Main motor power

7.5KW

7.5KW

Take up inverter power

7.5KW

7.5KW

Tension control method

Touch screen+PLC+magnetic powder clutch,

it may ensure the constant tension from empty bobbin to full bobbin

Magnetic powder clutch

5.0kgf

5.0kgf

Protection

Machine will automatically brake when wire inside and outside is broken,

the machine will automatically stop when the preset length is arrived.

Brake mode

Electromagnetic brake

Traversing method

Rolling ring drive units, winding pitch and breadth are adjustable

Operation mode

Touch screen operation

Dimension(mm)

10000L*2500W*1650H

10000L*2500W*1650H



Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine 0

Automatic Wire Cable Buncher Double Twist Buncher , Cable Bunching Machine 1
