15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device

Certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
Customer Reviews
The machine from Fuchuan is with high quality.We have confidence of its machine. And we have cooperation for many years. No 1 machine in China.

—— Mr Robert Klimko

I'm Online Chat Now

15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device

15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device
15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device 15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device 15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device 15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device

Large Image :  15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device

Product Details:
Place of Origin: China JiangSu
Brand Name: Fuchuan
Certification: ISO9001:2008
Model Number: FC-60+35
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD63300
Packaging Details: normal packing
Delivery Time: 45days
Payment Terms: T/T, L/C
Supply Ability: 500 sets one year

15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device

Description
Screw Dia: 60 Color: Sky Blue Or Grass Green
Screw Ratio: 25:1 Extrusion Output: 100
Max Speed: 600m/min Pay Off Bobbin: Diameter 500/630/800/mm
Material: PVC,PP,PE,SR-PVC
High Light:

wire stranding machine

,

cable stranding machine

15Kw Plastic Insulating Wire Extruder Machine Screw Dia 60mm With Double Layer Cooling Device





Quick Details:



Automobile wire high speed extruder line



Usage:

It is applied to extrude the PVC,PP,PE,SR-PVC and other plastic material for the automobile wire,insulated jacketed.



Characteristics:



Lut barrel up pay off machine,straighten ,main machine,injection machine,control case,water tank,double

wheel capstan,accumulator,double shaft take up and other equipments. The choice equipments: copper wire pre-heater,printer,OD measuring instrument,spark tester and PLC control or IPC operation. Save,display and revise technology parameter,remote control.



Specification:



1. Mechanical model: FC-60+35

2. Pay off type: 500-630active pay off or lut barrel up pay off

3.  Screw dia: 60

4.  Screw ratio: 25:1

5.  Revolving speed of screw: max 100rpm

6.  Extrusion output: 100kg/h

7.  Main power: 15kw

8.  Wire diameter: 0.8-5.0mm

9.  Cooling device: monolayer/double layer model U

10. Take up type:1246 automatic coiling machine,the plum blossom falls barrel machine,shaft type.



Other Information



FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
