Product Details:
Place of Origin: China JiangSu
Brand Name: Fuchuan
Certification: ISO9001:2008
Model Number: FC-200B
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: normal packing
Delivery Time: 45days
Payment Terms: T/T, L/C
Supply Ability: 500 sets one year

Photovoltaic Powerful Wire Extruder Machine Right Or Left Lay Direction

Color: Sky Blue Single Wire Dia(mm): Φ0.016~0.08
Stranding Section Area(mm²): 0.0014~0.035 Pitch(mm): 0.8-4.0(14 Classes)
Direction Of Lay: Optional For Right Or Left Take-up Bobbin(mm)  Outer Dia*bore*outer Width: Φ200*Φ31*135
High Light:

wire extrusion machine


wire stranding machine

Photovoltaic Powerful Wire Extruder Machine Right Or Left Lay Direction


Wire Extruder Machine Characteristics:


High production speed, constant tension from empty to full bobbin, especially for high quality stranding wire;Achieve bunching instead of twisting, especially for twisting small cross-section area;Use synchronous belt drive;Change guide wheel to change lay distance, easy to operate.


Wire Extruder Machine Merits:

  • High speed, good stability (the motor through the rigid coupling directly connected with the drive shaft)
  • Automatic tension control: When stranding, the reel take-up from the empty to the full , the tension must be increased (With the touch screen Free Set the data) The machine can automatically adjust the tension smoothly, keep the tension uniform variation ,Can achieve tension real time setting while working .
  • Electrical control: user-friendly touch screen interface operation, control by the PLC programmer + inverter
  • Flyer Bow :þ Japan imported SK5, finished with heat treatment, the surface of hard chrome þ Imported fiber glass Transmission system: drive with synchronous belts , laying accurate, no internal lubrication position, no waste products effect by refueling and machine cleaning
  • Change the lay length: easy to operate, just change the leading wheel according to the lay length sheet
  • Meter counting way: internal meter counter,
Twisting Usage Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).
Single Wire Dia(mm) Φ0.016~0.08 Φ0.03~0.18 Φ0.05~0.28 Φ0.05~0.32
Stranding Section Area(mm²) 0.0014~0.035 0.0049~0.3 0.0137~0.45 0.0137~1.0

0.8-4.0(14 Classes) 0.8-10.8(24 Classes) 1.6-21.6(24Classes) 3.1~33.3(24Classes)
Direction of Lay optional for right or left
Take-up Bobbin(mm)
Outer dia*bore*outer width
Φ200*Φ31*135 Φ250*Φ30*185 Φ250*Φ30*185 Φ300*Φ30*185 Φ300*Φ30*185 Φ400*Φ56*300
Max Rotating Speed(rpm) 5000RPM(10000TPM) 4000RPM(8000TPM) 3500RPM(7000 TPM) 3500RPM7000TPM)
Main Motor Power 2.2KW 3.7KW 3.7KW 3.7KW
Inverter Power 2.2KW 3.7KW 3.7KW 3.7KW
Tension Control Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic Powder Clutch 0.05kgf 0.3kgf 0.6kgf 0.6kgf
Protection automatically brake/stop 1)wire inside and outside is broken; 2)the preset length is arrived
Brake Mode Electromagnetic brake
Traversing Method Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation Mode Touch Screen Operation
Dimension 2000L*960W*1100H 2300L*1100W*1330H 2300L*1100W*1330H 2850L×1150W×1350H


Mechanical Performance

  • Body structure:

1.Material: low carbon steel welded together.

2.Structure: the body by annealing and aging, to eliminate internal stress, and then boring by a precision boring machine to forming a molding.

  • Bunching Entry part:

1.Bunching Entry position: facing to the front door, at the right side of the machine (can be customization according to customer requirements to change to the left side).

2.Bunching Entry Mode : from the pay-off device through the disconnection sensing area, first to the total sub-line board (sub-hole by 1 +6 +12 + ... distribution), through first pressure mold, then the second Pressure mold, after entering the right spindle within the wire guide wheel. From the aluminum arch with porcelain ring and then into the left spindle within the wire guide wheel, and then through the center corner’s guide wheel to the leading wheel, Final to the aligner’s guide wheel to cable laying (see wire bunching entry pattern diagram)

  • Spindle:

1.Material: 40Cr steel forging after quenching and tempering treatment.

2.Accuracy: The shaft core outer face diameter and the bearing end face are ground to ensure concentricity and verticality with the axis.

3.Dynamic balance: Standard of G2.5 (0.03g of weight difference)

  • ¨Aluminum plate / ¨ Rotation Arm

1.Material:¨ ZL104 / ¨45# steel

2.Accuracy: All end faces are positioned relative to the locating holes(less than 0.03 grams)

3.Dynamic balance: Accuracy of G2.5 (0.03 grams of weight difference)

  • Bow

1.Material: ¨ Japan imported SK5 ¨ Imported fiber glass

2.Shape: special appearance, reduce the wind resistance.

3.Weight tolerance : less than 0.03 grams per pair

  • Transmission part: with imported synchronous belt drive, laying length accurate
  • Wire entry wheel:

1.Material: # 45 steel finished with heat treatment HRC30-40.

2.Hard chrome plated on the surface, not easy to wear

  • Spindle housing:

1.Material: ductile iron QT42-10.

2.Processing: CNC machine tooling

3.Accuracy: one processing hole end molding, to ensure concentricity.

  • Spindle bearing lubrication system:

1.Lubrication method: butter lubrication

2.Butter Model: LGMT2

3.Sealing method: mechanical oil retaining ring, keep the machine clean inside

  • Take up:Tensile tension control through the magnetic clutch control thread tension, by the PLC program controller automatically adjust the tension, keep tension constant
  • Cable laying:Special two-way cable laying device, φ mm light rod bearing type,lay length and distance can be accurately adjusted


Description Model Origin
1.Host Motor   SIEMENS
2.Inverter   INOVANCE
3.PLC Programmer   INOVANCE
4.PLC Expander   INOVANCE
5.Touch Screen   Weinview
6.Electromagnetic Brake   WREZUN
7.Magnetic Clutch   CHAIN TAIL
8.Spindle Bearings 1SET SWEDEN SKF
Other Bearings 1SET JAPAN NSK
9.Timing Belt 1SET US GATES
10.Cable Laying Device   SHANXI Tian Xiang
11.¨Manual hydraulic pump   TAIWAN SHUNXIN
¨Electrical hydraulic pump
¨Electrical screw rod+Motor
12.Tension Controller   TAIWAN
13.Bow 1SET ¨Japan SK5 /¨Fiber glass
14.Body 1SET Self-processing
15.Spindle 2pcs Self-processing
16.Aluminum Plate 2pcs Self-processing
18.Bearing Housings 1SET Self-processing
19.Disc 2pcs Self-processing
20.Transmission Shaft 1pcs Subcontracting
21.Leading Wheel 1SET Self-processing with hard chrome plating
22.Wire guide wheel 6pcs Self-processing with hard chrome plating


  • Spare parts sheet
No. Description Model Qty Remark
1 Spindle guide wheel (with Bearings) 1SET
2 Wire guide wheel (with Bearings) 1SET
3 Loops in Bow   3pcs
4 Split plate porcelain ring Φ6.8 3pcs
5 Stranded Die Client provide
6-9 Timing belt   1pcs
10 Spool Top sleeve According to customer’s reel drawings 1SET
11 SKF Butter LGMT2/1



12 Grease gun   1pcs
13 Tool With hex wrench, open wrench and etc 1SET
14 Operating instructions   1SET
15 Electrical Schematic   1SET
16 Inverter manual   1pcs
