70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System

Certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
China Kunshan Fuchuan Electrical and Mechanical Co.,ltd certification
Customer Reviews
The machine from Fuchuan is with high quality.We have confidence of its machine. And we have cooperation for many years. No 1 machine in China.

—— Mr Robert Klimko

I'm Online Chat Now

70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System

70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System
70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System

Large Image :  70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System

Product Details:
Place of Origin: CHINA
Brand Name: FUCHUAN
Model Number: FC-70
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: Negotiable
Packaging Details: Simple water prof package
Delivery Time: 45-60 days
Supply Ability: 2Set/Month

70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System

Description
Material: PVC Direction: Left To Right
CrossHead: SOS316 Pay-off: 300-630mm Spool
Name: Wire Extruder Machine Accessory: Automatic Tension Adjusting System
High Light:

wire stranding machine

,

cable stranding machine

70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System



Wire Extruder Machine Quick detail :



Wire Extruder Machine applied to Ribbion Wire.Merits:

1. Integrated design of annealing and pre-heating, equipped with automatic tension adjusting system, and ensure the wire diameter uniformity of the copper wire elongation and conductor.

2. The plastic extruder main machine using non-adjustable crosshead, which can ensure concentricity of core wire over 95%.



Wire Extruder Machine structure:drawing machine,annealing machine,extruder,take up machine,tester and other equipments.



Wire Extruder Machine Specification:



No.

Name/ Specification



Qty

Unit

Remark

  •

12H 500 Pay-off

1 Set For 500 ABS spool
  •

Straighten Unit

1 Set Fuchuan
  •

Ribbion wire Cross-head

1 Pcs ≤30.0mm
  •

¢70 Extruder

1 Set Fuchuan(with PVC screw)
  •

1.8MMovable Water Tank

1 Set Fuchuan
  •

Dryer Hopper

1 Set Fuchuan
  •

Diameter Gauge

  Set SHANGHAI ON-LINE
  •

4M Double Layer Water Tank

1 Set Fuchuan
  •

200KG Capsten Device

1 Set For flat wire only
  •

159 Meter Counter

1 Set Fuchuan
  •

800/630 Double shaft take-up

1 Set Fuchuan
  •

Suction Machine(For 70 extruder)

1 Set TAIWAN SHIN
  •

Electrics

1 Set Japan's RKC temperature controller;Siemens Motor, Japan's Omron relay and France Schneider Electrics, Germany's Siemens PLC + Taiwan Veiview touch-screen control, +Alarm screen



Other information:



active pay off or passive pay off



Terms of payment:



FOB Shanghai / Ningbo



Payment terms:



30% down payment,70% before shipment



Delivery time:



45-60 days after receive the downpayment



Origin:



China



Minimum order:



1set



Package:



With container



70 Screw Rod Ribbon Wire Extruder Machine With Automatic Tension Adjusting System 0
