Sky Blue Ultra Fine Wire Cable Braiding Machine Single Dia 0.03mm - 0.32mm

China Sky Blue Ultra Fine Wire  Cable Braiding Machine Single Dia 0.03mm - 0.32mm supplier
Sky Blue Ultra Fine Wire  Cable Braiding Machine Single Dia 0.03mm - 0.32mm supplier Sky Blue Ultra Fine Wire  Cable Braiding Machine Single Dia 0.03mm - 0.32mm supplier Sky Blue Ultra Fine Wire  Cable Braiding Machine Single Dia 0.03mm - 0.32mm supplier Sky Blue Ultra Fine Wire  Cable Braiding Machine Single Dia 0.03mm - 0.32mm supplier

Large Image :  Sky Blue Ultra Fine Wire Cable Braiding Machine Single Dia 0.03mm - 0.32mm

Product Details:

Place of Origin: China
Brand Name: Fuchuan
Certification: ISO9001 2008
Model Number: FC-250B / 300B / 400B

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: with container
Delivery Time: 45days
Payment Terms: L/C, T/T
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Color: Sky Blue Take Up Bobbin: Dia 200 250 300 400mm
Fit Wire Diameter: 0.03mm To 0.32mm Wire: Alloy Wires, Tinned Wires, Silver Jacketed Wires And Enamelled Wires
Operation Mode: Touch Screen Operation Direction Of Lay: Free To Left Or Right

China Fuchuan Ultra Fine Wire Cable Twisting Machine Single Dia 0.03mm-0.32mm



Quick Details:


A. Japanese Technology ,Product in China



B. It has been developed to produce very accurate strands with very small sections for the electronic industry. Simultaneously produce two different strand sections, on equal or different reels.One motor drive two shafts can be more environmental and power. With the main shaft meter counter, the machine twist the same types of line, and the tolerance is only 0.01%.



C. Patent No.:201320522156.7

D. Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).

Characteristics:

A. High production speed, constant tension from empty to full bobbin, especially for high quality stranding wire.

B. Especially for twisting small cross-section area.

C. Use synchronous belt drive,

D. Use shaft to calculate meters, less than 0.01% error for a certain wire&cable.

E. With FC-100 active back-twist pay-off machine to achieve bunching instead of twisting.

F. Change guide wheel to change lay distance, easy to operate.


Specifications:



Equipment Models FC-200B FC-250B-1 FC-300B-1 FC-400B-1
Twisting Usage Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).
Single Wire Dia(mm) 0.016~0.08 0.03~0.18 0.05~0.28 0.05~0.32
Stranding Section Area(mm²) 0.0014~0.035 0.0049~0.3 0.0137~0.45 0.0137~1.0
Pitch(mm) 0.8~4.0(14 classes) 0.8~10.8(24classes) 1.6~21.6(24classes) 3.1~33.3(24classes)
Direction of Lay Free to right or left

Take-up Bobbin(mm)

Outer dia*bore*outer width

200*31*135 300*30*185

250*30*185

300*30*185

300*30*185

400*56*300

Max Rotating Speed(rpm) 5000rpm(10000tpm) 4000rpm(8000tpm) 3500rpm(7000tpm) 3500rpm(7000tpm)
Main Motor Power 2.2KW 3.7KW 3.7KW 3.7KW
Inverter Power 2.2KW 3.7KW 3.7KW 3.7KW
Tension Control Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic Powder Clutch 0.05kgf 0.3kgf 0.6kgf 0.6kgf
Protection

automatically brake/stop 1)wire inside and outside is broken

2)the preset length is arrived

Brake Mode Electromagnetic brake
Traversing Method Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation Mode Touch Screen Operation
Dimension L*W*H 2000*960*1100 2300*1100*1330 2300*1100*1330 2850*1150*1350


Other Information


FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
