FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2

China FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2 supplier
FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2 supplier FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2 supplier FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2 supplier FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2 supplier

Large Image :  FC-250B Wire Twister Machine Stranding Section Area 0.0049 To 0.3mm2

Product Details:

Place of Origin: China
Brand Name: Fuchuan
Certification: ISO9001 2008
Model Number: FC-250B

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: with container
Delivery Time: 45days
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Color: Sky Blue Take Up Bobbin: Diameter 300mm
Fit Wire Diameter: 0.03mm-0.18mm Wire: Alloy Wires, Tinned Wires, Silver Jacketed Wires And Enamelled Wires
Direction Of Lay: Free To Left Or Right Operation Mode: Touch Screen Operation

Fuchuan FC-250B Ultra fine Wire Twisting Machine with Stranding Section Area 0.0049 to 0.3mm2


Quick Details:

Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).

Characteristics:


1. High production speed, constant tension from empty to full bobbin, especially for high quality stranding wire.

2. Use shaft to calculate meters, less than 0.01% error for a certain wire&cable.

3. With FC-100 active back-twist pay-off machine to achieve bunching instead of twisting.

4. Especially for twisting small cross-section area.

5. Use synchronous belt drive,

6. Change guide wheel to change lay distance, easy to operate.


Specifications:



Equipment Models FC-200B FC-250B FC-300B FC-400B
Twisting Usage Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).
Single Wire Dia(mm) 0.016~0.08 0.03~0.18 0.05~0.28 0.05~0.32
Stranding Section Area(mm²) 0.0014~0.035 0.0049~0.3 0.0137~0.45 0.0137~1.0
Pitch(mm) 0.8~4.0(14 classes) 0.8~10.8(24classes) 1.6~21.6(24classes) 3.1~33.3(24classes)
Direction of Lay Free to right or left

Take-up Bobbin(mm)

Outer dia*bore*outer width

200*31*135 300*30*185

250*30*185

300*30*185

300*30*185

400*56*300

Max Rotating Speed(rpm) 5000rpm(10000tpm) 4000rpm(8000tpm) 3500rpm(7000tpm) 3500rpm(7000tpm)
Main Motor Power 2.2KW 3.7KW 3.7KW 3.7KW
Inverter Power 2.2KW 3.7KW 3.7KW 3.7KW
Tension Control Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic Powder Clutch 0.05kgf 0.3kgf 0.6kgf 0.6kgf
Protection

automatically brake/stop 1)wire inside and outside is broken

2)the preset length is arrived

Brake Mode Electromagnetic brake
Traversing Method Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation Mode Touch Screen Operation
Dimension L*W*H 2000*960*1100 2300*1100*1330 2300*1100*1330 2850*1150*1350


Other Information


FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
