Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation

Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation
Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation

Large Image :  Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation

Product Details:
Place of Origin: China
Brand Name: Fuchuan
Certification: CE
Model Number: FC-650C-5
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: with container
Delivery Time: 45days
Payment Terms: L/C, T/T
Supply Ability: 500 sets / per month

Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation

Description
Color: Sky Blue Take Up Bobbin: DIA 630mm
Fit Stranding Section Area: 0.3mm To 4mm Wire: Bare Copper Wires, Tinned Wires, Silver Jacketed Wires And Enameled Wires),double Twisting For Core Wires
Operation Mode: Touch Screen Operation Direction Of Lay: Free To Left Or Right
High Light:

wire twister machine

,

automatic wire twisting machine

China Fuchuan Medical Equipment Regular Wire Twisting Machine With Japan Technology


Quick Details:

Apply for the twisting medical equipment, cellphone, aerospace and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.

Characteristics:

Japan Technology, product in China
New developed, mainly apply for stranding the electrical wire and automobile wire and other small section area conductor.
High rotation speed, max up to 2600rpm, is the 1.6 times than normal (1600rpm);
1. Use PLC, hysteresis clutch take-up device imported from German, tension sensor ensure the stable tension and high quality stranding wire, especially for high quality tight line.
2. Use carbon fiber bow, strong rigidity, uneasy-transformation, small shock, light weight, reduce air friction for high quality of conductors;
3. High rotation speed, max up to 2600rpm, is the 1.6 times than normal (1600rpm);
4.Use PLC automatically lubricate spindle bearing, avoid injecting too much or too little grease. Get rid of unnormal noise and worn, cost down for maintenance.
5.Use synchronous belt drive, just to replace the guide wheel to change the lay distance, easy to operate.
6.Use spindle to calculate meters, only 0.01% error for a certain wire&cable.

Specifications:

Equipment modelsFC-500BFC-650BFC-650C-5FC-800B
Twisting usageApply for twisting aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.
Single wire dia(mm)0.08-0.450.15-1.040.12-0.520.38-1.70
Stranding section area (mm²)0.05-2.50.35-6.00.30-4.01.0-16
Core wire single wire dia(mm)0.5-1.50.5-3.00.5-2.01.0-4.0
Core wire stranding outer dia(mm)1.0-3.51.0-6.01.0-4.02.0-8.0
Pitch(mm)6.3-52.3(24classes)11.6-100(34classes)11.6-100(34classes)23-147(20classes)
Direction of layOptional for right or left
Outer dia*bore*outer widthOD500 ID56 H375OD630 ID56 H475

OD630 ID56 H475
OD630 ID127 H475

OD800 ID80 H600


Max rotating speed3000rpm(6000twist)2000rpm(4000twist)2400rpm(4800twist)1500rpm(3000twist)
Main motor power5.5KW7.5KW11KW15KW
Inverter power5.5KW7.5KW11KW15KW
Tension control methodTouch screen +PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic powder clutch1.2kgf5kgf2.5kgf10kgf
Protection

automatically brake/stop 1)wire inside and outside is broken
2)the preset length is arrived

Brake modeElectromagnetic brake
Traversing methodRolling wire with ring drive units, winding pitch and breadth are adjustable
Operation modeTouch screen operation
Dimension(mm)2680L 1250W 1500H3300L 1550W 1800H3300L 1550w 1800H4600L 2000W 2000H



Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container

Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation 0
Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation 1
Medical Regular Wire Twister Machine Japan Technology Touch Screen Operation 2
