Product Details:
|
| Name: | Wire Machinery | Fit For Bobbin: | Diameter 630mm |
|---|---|---|---|
| Fit Copper Wire: | 0.08mm-0.64mm | Type: | Active |
| Fit For Wire: | Bare Copper Wire | Tension Control: | Pneumatic Tension |
| Fasten Type: | Pneumatic Fasten | Used For: | Double Wire Pay Off |
| High Light: | automatic wire twister,cable twisting machine,active cable twisting machine |
||
Active Pay Off Machine Multiple Drawing Bobbins For Bunched Copper Wire
Quick Details:
It is constant tension,non-twist wire single bobbin pay off machine.Applied to single wire and multiple drawing wires pay off. Match up with the high speed bunching machine,easy to operate,save more floor area.
Specifications:
Model: FC-630-2 double shaft active pay off machine
Usage: Applied to doubling wire pay off, match up with the high speed bunching machine.
Single wire diameter: dia0.08-0.64mm
Pay off bobbin: PND630
Motor power:1.5KW
Tension control: Pneumatic tension
Wire speed: It is feedback the singnal to the inverter to control the rotating speed of motor by displacement sensor.
Control type: Synchronize with the main machine
Protection: Machine is stopped when wire is broken.
Fasten type: Pneumatic fasten
