Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire

Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire
Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire

Large Image :  Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire

Product Details:
Place of Origin: China JiangSu
Brand Name: Fuchuan
Certification: ISO9001:2008
Model Number: FC-1250-1
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD30000
Packaging Details: normal packing
Delivery Time: 45days
Payment Terms: T/T
Supply Ability: 20SET/PER MONTH

Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire

Description
Color: Sky Blue/apple Green Fit For Bobbin: Diameter1250mm
Wire: PE/PVC Core Wire Or Copper Wire Fit For Wire: Dia1.0mm-6.0mm
Max Speed: 400rpm Direction Of Lay: Righ Or Left
Pitch: 50-400 Max Twist Diameter: 30mm
Type: Gear
High Light:

wire buncher machine

,

electric wire making machine

Cable Laying Single Twist Machine Gear Pitch For PE / PVC Core Wire





Quick Details:



Series for 1250 gear type single twist (cable laying) machine



Characteristics:



It is mainly used in cable laying of computer wires, such as data cable and control cable. It may synchronize central coil tapping and side coil tapping. The entire machine is consists of pay off rack, central  bundler, side pay off rack for the central coil tapping set, single twist(cable-laying)machine and electrical control cabinet.



Specifications:



Equipment models

FC-1250

Twisting usage

It is applied to the twisting of PVC/PE core wire or copper wire, central bundling or side bundling.

Applicable dia(mm)

φ1.0-φ6.0

Max twist outer dia

φ30

Pitch(mm)

50-400

Direction of lay

Optional for right or left

Take-up bobbin size

φ1250

Max rotating speed(rpm)

400

Traversing method

Traverse is adopt crossbar-less reciprocating

Take up tension

Pneumatic tension automatic regulate

Brake mode

Disc brake

Bundling mode

Central bundling or side bundling

Replace pitch mode

Computer pitch or gear pitch













































Other Information


FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
